SKYJACK 4632 SCISSOR LIFT
Availability:
RENT NOW
| SJIII 4632 | ||
|---|---|---|
| Work Height | 38’ (11.58 m) | |
| Raised Platform Height | 32’ (9.75 m) | |
| Lowered Platform Height | 48.5” (1.23 m) | |
| Overall Width | 46” (1.17 m) | |
| Overall Length | 91” (2.31 m) | |
| Stowed Height (Rails Up) | 88” (2.24 m) | |
| Stowed Height (Rails Down) | 74” (1.88 m) | |
| Platform Width (Inside Dimension) | 42” (1.07 m) | |
| Platform Length (Inside Dimension) | 84” (2.13 m) | |
| Extension Deck (Roll Out) | 4’ (1.22 m) | |
| Ground Clearance (Stowed) | 3.5” (8.89 cm) | |
| Ground Clearance (raised) | 0.75” (1.91 cm) | |
| Wheelbase | 69” (1.75 m) | |
| Weight | 5,075 lbs (2,302 kg) | |
| Gradeability | 25% | |
| Turning Radius (Inside) | 47.5” (1.21 m) | |
| Turning Radius (Outside) | 93.5” (2.37 m) | |
| Lift Time (With Rated Load) | 59 sec | |
| Lower Time (With Rated Load) | 49 sec | |
| Drive Speed (Stowed) | 2 mph (3.2 km/h) | |
| Drive Speed (Raised) | 0.6 mph (1 km/h) | |
| Maximum Drive Height | Full Height | |
| Capacity (Overall) | 700 lbs (318 kg) | |
| Distributed Capacity (Main Platform) | 450 lbs (204 kg) | |
| Distributed Capacity (Extension Deck) | 250 lbs (113 kg) | |
| Local Floor Load (With Rated Load) | 220 psi (1517 kPa) | |
| Overall Floor Load (With Rated Load) | 204 psf (10 kPa) | |
| Maximum # of Persons | 2 | |
| Wind Rating | 28 mph (12.5 m/s) | |
| Tire Type | Solid, N/M | |
| Tire Size | 16 x 5 x 12 |
Day: $255
Week: $600
Month: $1400
An order can be placed over the phone, or in person at either of our locations. A driver’s license and security deposit are needed for reservations.
We recommend reserving your item as soon as you know what is desired due to a first come first serve policy. Our busiest months are from May – October. You may reserve the maximum amount of items necessary, and then bring your counts down as the event planning develops.
We typically deliver 1-2 days prior to a job. We typically request a 4 hour window between 7 am – 4 pm Monday – Friday and we do not deliver on Saturday or Sunday. There may or may not be an additional fee for delivery at a specified time, or after normal hours of operation. We will do our best to accommodate your needs.
